If a computer analysis gives a period of 0. SDOF Dynamics In some cases, it is appropriate to remove the conservatism from the empirical period formulas. This is done through use of the C u coefficient. This conservatism arises from two sources: 1.

### Evaluation Copy

The lower bound period was used in the development of the period formula. The empirical formula was developed on the basis of data from California buildings.

Buildings in other parts of the country e. It is important to note that the larger period cannot be used without the benefit of a properly substantiated analysis, which is likely performed on a computer. ASCE will not allow the use of a period larger than C u T a regardless of what the computer analysis says. Note the similarity with the undamped solution. In particular, note the exponential decay term that serves as a multiplier on the whole response. Critical damping c c is defined as the amount of damping that will produce no oscillation.

See next slide. The damped circular frequency is computed as shown. The exception is very highly damped systems. A good example of a critically damped response can be found in heavy doors that are fitted with dampers to keep the door from slamming when closing. However, for low damping values, viscous damping allows for linear equations and vastly simplifies the solution. It is frictional or hysteretic. Viscous damping is used simply because it linearizes the equations of motion.
